Conductor: Bare copper stranded wire, compliant with IEC 60228, EN 60228, VDE 02956
Insulation: PVC TI2, compliant with DIN VDE 0281 + HD 211
Color Code: Black cores with continuous numbering, compliant with EN 50334, plus one yellow-green ground wire
Core Structure: Layered
Inner Sheath: PVC (SC712C)
Shielding: Tin-plated copper braided shield
Outer Sheath: PVC, TM2 compliant with DIN VDE 0282 + HD 22.1
Sheath Color: Grey (RAL 7000)
Technical Specifications
Rated Voltage: Uo/U 0.6/1 kV
Test Voltage: 4000V core/shield, 2000V
Minimum Bending Radius: SC712C: 5xD, SC710: 4xD
Fixed Installation: 5xD
Mobile Installation: 10xD (SC712C), 6xD (SC710)
Operating Temperature
Fixed Installation: -40°C to +70°C
Mobile Installation: -5°C to +70°C
Radiation Resistance: 8x10^7 cJ/kg
Oil Resistance: Suitable for light machine oil, gear oil, lubricating oil, etc.
Characteristics and Compliance
Characteristics: ◆ Strong performance ◆ Easy installation ◆ Excellent electromagnetic properties
Certifications:
Typical Applications
Suitable for fixed installation and flexible use, such as in machines and industrial factories with general mechanical requirements in dry, humid, and highly humid environments. Examples include automation technology, control and production engineering, robotics, industrial construction, motor construction, drive systems, and power cables between frequency converters and servo motors.
